SHANGHAI SANFU CHEMICAL CO.,LTD.
SF N7100
SF N7100
Couldn't load pickup availability
Share
Product Description:
SF N7100 is an environmentally friendly fluorine solution with zero ozone depletion potential and low global warming potential, which can be used as a replacement for solvents such as HCFC-141b, HCFC-225, CFC-113, nPB, etc. SF N7100 has similar physicochemical properties to 3M Novec 7100 and can be used as an equivalent replacement for Novec 7100 in cleaning, liquid cooling, thermal conductivity, solvents, lubricants and other applications. Meanwhile, SF N7100 has similar physicochemical properties to 3M Novec 7100, and can be used as an equivalent replacement for Novec 7100 in cleaning, liquid cooling, thermal fluid, solvents, lubricant diluents and other applications. In addition, SF N7100 can also be pure monomers, azeotropic or azeotropic components and azeotropic solutions, etc., to form a low surface tension, low viscosity, strong wettability, non-flammability, stability, and good solubility of impurities such as oil and dirt in the submerged and vapor degreasing applications can be used as an ideal choice for a wide range of electronic products, semiconductors and other precision cleaning applications. Given its low boiling point and fast volatility properties, SF N7100 can be used as an industrial specialty solvent for specialty coating applications such as electronic coatings.
Advantages:
Excellent environmental attributes, specifically low GWP and zero ODP, can effectively replace HCFC-141b, HCFC-225, CFC-113, nPB and other chemicals used in cleaning and solvent applications;
Suitable physicochemical properties, can be an equivalent replacement for the 3M Novec 7100 product;
Low surface tension, good grease solubility and fast evaporation potential, can be used in many forms of cleaning environments and specialty solvents, can better remove stains; Low boiling point and fast evaporation rate, faster evaporation and recycling, does not leave traces Low surface tension, good grease solubility and fast evaporation potential, can be used in various cleaning environments and specialty solvents to remove stains well;
Low boiling point and fast evaporation rate, can be evaporated and recycled quickly without leaving traces;
High insulation and flammability, provide sufficient conditions for cleaning, heat transfer and liquid cooling of semiconductors, electronic equipment, data centers, etc.;
Non-flammable, low odor, low toxicity and good thermal stability, provide good conditions for safe operation, transportation and storage. Non-flammable, low odor, low toxicity and good thermal stability, providing good conditions for safe operation, transportation and storage
Application Areas:
Thermal Conductivity Fluid; Data Center Submerged Liquid Cooling; Steam Cleaning, Precision Instrument Cleaning, Optical Cleaning, etc. The azeotropic solution can be used for heavy oil type cleaning (lubricants, fluxes, heavy fuel oils, etc.), the azeotropic solution can be used for medium-sized grease cleaning (oils, greases, waxes, etc.) and the pure component can be used for medium-sized grease cleaning (particles, fluorinated solvents, light oils, fluorinated polymers, etc.); dielectric test media; Lubricant carriers; specialized solvents, etc.
Physical and chemical properties:
Physical and chemical properties |
unit |
SF N7100 |
3M Novec7100 |
Molecular mass |
g/mol |
250 |
250 |
Boiling |
℃ |
61 |
61 |
Freezing point |
℃ |
-135 |
-135 |
Density @ 25°C |
g/ml |
1.52 |
1.51 |
Viscosity@25℃ |
mPa.s |
0.57 |
0.57 |
Surface Tension@25℃ |
mN/m |
13.6 |
13.6 |
latent heat of evaporation |
KJ/Kg |
126 |
126 |
Evaporation rate |
(aniline=100) |
49 |
49 |
Specific heat@25℃ |
KJ/kg.K |
1.183 |
1.172 |
Volume resistivity@25℃ |
Ω.m |
108 |
108 |
Dielectric Breakdown Voltage |
KV |
28 |
28 |
KB |
|
>25 |
>25 |
Flash point |
℃ |
None |
None |
ODP |
|
0 |
0 |
GWP |
|
287 |
320 |
